Platinum Series WindowsBellagio Series WindowsVenetian Series Windows
Horizontal Slider Windows
333-Horizontal Slider
424-Horizontal Slider


Horizontal slider vinyl windows are composed of two sash each—one that’s stationary and one that slides to the left or right on grooves or tracks. The operating sash can be removed to make cleaning a snap. Every moving window comes with an extruded aluminum screen frame with a lift handle rail for easy  removal. The vinyl track rail system and tandem brass rollers offer smooth sliding operation and lifetime durability. All Green World Windows are tested by AAMA and NFRC and are Energy Star Approved and Rated.

  • Features
  • Hardware
  • Frame Color
  • Glass
  • More Option
  • Egress Tables
  • STC
  • Cross Section
  • Installation Instructions
  • NFRC
  • Brochures
  • Structural Ratings
Nail-on Outside ViewRetrofit Outside View Inside View
  •  Auto Action Lock.

  •  Frame with 3 1/4' depth and designed with brick mold detail to provide a traditional wood window look.

  •  Precision-mitered, fusion-welded frame corners are smooth and permanently weather-tight.

  •  Multi-Chambered frame and dual wall retrofit fin provide better thermo insulation, structual strength and easy installation.

  •  Aluminum reinforced meeting rail and interlock provide a lifetime of security and strength.

  •  Dual pane 3/4' I.G.glass unit provide superior energy efficiency and noise reduction.

  •  Available in white and almond.

  •  Also available in power wall frame.

Auto Lock
LockedUnlocked
Manual Lock
Roller

Stand : Frame Colors - Interior and exterior colors must be the same.

AlmondWhite

capstock:Capstock Colors exterior,interior is white

Silver
EspressoBrown
Sage greenChocolateBronze



Obscure-GreenWorld’s obscure glass gives privacy and style for windows and doors throughout your home, and is ideal for locations requiring more privacy such as bathrooms.


Standards -Green World Windows  meets the following standards.


_______________________________________________________________________________________________

Grid Types -You can choose from 5/8” flat grids to give you the most viewing area, or 1” sculptured grids, which will add a rich architectural detail to your windows. There are many patterns available, and maybe even some that you could create.

新建位图图像.bmp新建位图图像 (2).bmp图像.bmpblob.png
Peremeter
Queen Anne

Marginal

F-DL(4W2H)

Possible Combinations


PLANNING AND BUILDING DEPARTMENT

EMERGENCY ESCAPE AND RESCUE WINDOWS

All sleeping rooms in dwelling units below the fourth floor shall have at least one operable window or door approved for emergency escape or rescue. The emergency window or door shall be operable from the inside to provide a full, clear opening without the use of separate tools. Escape or rescue windows shall have a minimum net clear openable area of 5.7 square feet. The minimum net clear height dimension shall be 24 inches. The minimum net clear width dimension shall be 20 inches. When windows are provided as a means of escape or rescue, they shall have a finished sill height not more than 44 inches above the floor.

The below is Platinum S-3200/3300 Egress Table:



Operating StyleSeries NumberGlass 1Air SpaceGlass 2STCEWROITC
Horizontal SliderS-3200
S-3300
SS1/2SS283023
SS1/2SS293023
DS1/2SS303326
DS1/2DS313326
DS5/8DS323428
3/165/8DS333428
3/165/8DS343428
3/163/4DS353731
3/163/4DS363731
1/45/83/16373932
1/45/83/16383932

PLANNING AND BUILDING DEPARTMENT

EMERGENCY ESCAPE AND RESCUE WINDOWS

All sleeping rooms in dwelling units below the fourth floor shall have at least one operable window or door approved for emergency escape or rescue. The emergency window or door shall be operable from the inside to provide a full, clear opening without the use of separate tools. Escape or rescue windows shall have a minimum net clear openable area of 5.7 square feet. The minimum net clear height dimension shall be 24 inches. The minimum net clear width dimension shall be 20 inches. When windows are provided as a means of escape or rescue, they shall have a finished sill height not more than 44 inches above the floor.

The below is Platinum S-3200/3300 Egress Table:




Brochures:

S-3300.pdf
